ALT02 (Toughened nylon 66)

Description

• Product Name: PA66-I
• Product grade: Injection molding grade.
• Product features: Toughened nylon 66, with excellent low-temperature impact resistance (-30℃), meets ROHS requirements.
• Product color number: Black
• ALT02 is a rubber toughened PA66 for special use, it performs prominent anti-impact strength at low temperature(-30℃), meet the requirements of ROHS.
• Product applications: Low temperature impact resistant parts, etc.

Typical molding process

Dry	Drum wind oven:           100～120℃, 4～6h；Cycling warm air:           100～120℃,4～6h；Vacuum drying oven：      100～120℃,3～4h；
Processing temperrature	Feed section：275～290℃Compressing section：280～300℃Metering secion：280～300℃
Injection pressure	70～130MPa
Packing pressure	50～100 MPa
Mold temperature	50～90℃
Back pressure	5～15MPa

Parameter

Test Item	Test Standard	Test Condition	Unit	Value
Others
Product Identification	ISO1043	——	——	PA66-I
Filler Content	ISO3451-1	——	%	/
Density	ISO1183	23℃	g/cm³	1.10
Molding shrinkage(parallel/ normal)	ISO 294-4	——	%	0.8/1.3
Melt Flow Rate	ISO 1133	275℃，2.16kg	g/10min	35
Viscosity number	ISO307	96%H2SO4,0.5g/dl	ml/g	–
Mechanical
Flexural Strength	ISO178	23℃，2mm/min	MPa	90
Flexural Modulus	ISO178	23℃，2mm/min	MPa	2200
Tensile Strength	ISO527	Type I spline,50mm/min	MPa	65
Charpy Notched Impact Strength	ISO179/1eA	23℃	kJ/m2	14/C
Charpy Unnotched Impact Strength	ISO179/1eU	23℃	kJ/m2	N
Izod Notched Impact Strength	ISO180/1eA	23℃	kJ/m2	/
Izod Unnotched Impact Strength	ISO180/1eU	23℃	kJ/m2	N
Thermal
Melting Temperature	ISO11357	——	℃	250
Electrical
CTI	IEC60112	A	V	/
Volume Resistivity	IEC60093	——	Ω•cm	1014
Surface resistivity	IEC60093	——	Ω	1013
Flammability
Flammability	UL-94	1.6mm	Class	HB

All is typical data, only for reference, not the permit of quality assurance.
